Ridetech Panhard bar kit for 2000-2006 GM HD. For use with universal HD 4-Link 11459099

Ridetech Panhard bar kit for 2000-2006 GM HD. For use with universal HD 4-Link 11459099
Ridetech Panhard bar kit for 2000-2006 GM HD. For use with universal HD 4-Link 11459099Ridetech Panhard bar kit for 2000-2006 GM HD. For use with universal HD 4-Link 11459099
$525.99 kt
NEWARRIVING SOONEstimated Ship Date 04/24/2025 (If Ordered Today)3 Available from RIDETECH as of 04/04/2025
Model: 3429589
Select a Vehicle or refer to the Vehicle Fitment Tab below to verify that this part fits your vehicle.
TRUCK
FREIGHT
STORE PICKUP
[More Info]

Heavy duty trucks are the perfect application for an air suspension. The weight load of these truck can vary by several thousand pounds from trailers, people, or other cargo. With a traditional leaf spring suspension, you are forced to endure a harsh ride quality when unloaded in order to accommodate any anticipated cargo when loaded. With air suspension, however, you can adjust the spring rate via air pressure to be appropriate for any cargo load, light or heavy!

The new HD 4-Link rear suspension will fit a wide variety of heavy trucks but is primarily designed for lowered trucks. The HD 4-Link offers a huge improvement in not only ride quality but also load capacity and handling performance as well. By virtue of its highly adaptable design and weld-on installation, it will fit a wide range of 3/4 ton and 1-ton trucks.

The HD 4-Link features 1.5″ diameter .188″ wall DOM tube 4-Link bars, the R-Joint XL Rod Ends, 2″ diameter .250″ wall tubing bridge, .250″ thick plate steel brackets, and Firestone air springs with a total load capacity of around 7,000 lbs.

Popular options for the HD 4-Link include the new Ridetech impact forged Monotube shocks, your choice of universal or model specific panhard bar kits, and a variety of compressor and control systems to fit any budget or performance level.

Vehicle specific and universal weld-on panhard bars listed below.

About Ridetech

Ridetech manufactures exciting suspension systems that improve the handling and ride quality of your muscle car, truck, Corvette or hot rod. From restorations and show cars, to high-speed autocross and track day cars, Ridetech offers a wide range of premium products including air suspension systems (air ride), coil-overs, shock absorbers, coil and leaf springs, tubular control arms, roll bars, sway bars and much more.

Downloads:

Download Name File Size
installation_instructions_11006799_11006798_11006797.pdf523.86KB

Vehicle Fitment:

The Vehicle Fitment Guide is to be used as a general reference. The data has been provided by our suppliers and manufacturers and may contain errors or incorrect data. Always refer to a professional to verify correct fitment for your vehicle.
Make Model Years
Chevrolet Silverado 3500 2001 - 2006

Specifications:

Part Type Suspension Trailing Arm / Panhard Rod Kit
Pricing Group Panhard Bar Kit
Prop 65 Chemicals chromium,nickel,nickel_compounds
Proposition 65 Warning Y
Warranty Time 1 Months
