Model A Ford Camshaft - Reground - Touring Style Grind - 3 Bearing Style Service

Model A Ford Camshaft - Reground - Touring Style Grind - 3 Bearing Style Service
Model A Ford Camshaft - Reground - Touring Style Grind - 3 Bearing Style Service
$120.99 ea
NEWARRIVING SOONEstimated Ship Date 11/25/2024 (If Ordered Today)
Model: 3232770
Select a Vehicle or refer to the Vehicle Fitment Tab below to verify that this part fits your vehicle.
STANDARD
DELIVERY
STORE PICKUP
[More Info]

Due to lack of cores, you must send your original in to be rebuilt. Click on Print Service Form.

Provides increased torque & horsepower.



Camshaft Specifications:

Shaft diameter: 7/8"

Bearing diameter: 1.560"

Block bore diameter: 1.561"

Bearing clearance: (MAX.) .003"

Bearing length: Front, 1-3/4"; Center, 2"; Rear, 1"; 4th (1928), 7/8"

Lift of cam: .300"

Duration: 200 º

Lobe center angle: 113-1/2º

End play spring tension: Approximately 35 pounds

Timing gear mounting flange: 2-5/16" diameter, 5/16" thick

Camshaft material: Special Ford carbon manganese

steel

Cam shaft gear: Bakelized material

Number of gear teeth: 50

Camshaft gear type: Spiral teeth

Gear backlash: .003" to .005"

Gear rotation speed: 1/2 of crankshaft

Camshaft straightness: .0005" to .001"

Variation in eccentricity of pitch diameter of gear teeth: .0015"

Variation in maintaining center distance of mating gears: +/- .001"

Gear tolerances in regular spacing of teeth: 0.0"



Vehicle Fitment:

The Vehicle Fitment Guide is to be used as a general reference. The data has been provided by our suppliers and manufacturers and may contain errors or incorrect data. Always refer to a professional to verify correct fitment for your vehicle.
Make Model Years
Ford Model A 1928 - 1931
